Description
Product Information
SKU011544
Mfr Part#24B2XH
UPC685417721085
Display
Screen Size:23.8″
Panel Type:IPS
In Plane Switching (IPS) Support:IPS
Color:Black
Features:Kensington Lock Slot
Widescreen:Yes
Maximum Resolution:1920 x 1080
Pixel Pitch:0.2745mm
Native Refresh Rate:60Hz
Refresh Rate Details:60 Hz using HDMI
Response Time:8ms
Brightness:250 cd/m2
Native Contrast Ratio:1,000:1
Viewable Size:23.8″ Viewable Diagonal Size
Dynamic Contrast Ratio:20,000,000:1
Screen Coating:Anti-Glare
Aspect Ratio:16:9
Viewing Angles:178 horizontal / 178 vertical viewing angles
Supported Resolutions:1928 x 1080, 1680 x 1050, 1440 x 900, 1280 x 960, 1280 x 720, 1280 x 1024, 1024 x 768
Color Output:16.7 Million
Horizontal Scan Range:30 KHz – 83 KHz horizontal scan range
Vertical Scan Range:50 Hz – 76 Hz vertical scan range
Features
Stand Adjustment:Tilt
Tilt Range:-3.5 degrees to +20 degrees
Built-in Devices
Built-in Devices:Kensington Lock
Controls
Controls:Source/Auto/Exit, Clear Vision, Volume, Menu/Enter, Power
On-Screen Controls:On Screen Display Menu
Front Panel Controls:Source (VGA/HDMI), <,>, Menu, Power ON/OFF
Connectivity
Ports:1 x 3.5 mm Headphone
1 x VGA 15-pin
1 x HDMI 1.4
Power
Voltage Required:100 to 240 VAC / 50 or 60 Hz
Power Consumption Operational (Standby):19 Watts (<0.5>
Certifications:Energy Star
Physical Specifications
Box Dimensions (WxDxH):18.39 x 4.17 x 11.50 in. (467.11 x 105.92 x 292.10 mm)
VESA Mount Compatibility:100mm x 100mm (3.9 x 3.9 in.)
Width:21.23 in. (539.24 mm)
Depth:6.73 in. (170.94 mm)
Height:16.47 in. (418.34 mm)
Weight:9.91 lbs. (4.50 kg)
Environmental Specifications
ROHS Compliant:Yes
Certifications:CE
cTUVus
Gost
Package Contents
What's in the Box:23.8″ Monitor, Power Cord, HDMI cable, Quick Start Guide
Warranty
Parts:3 Years
Labor:3 Years
